    YUMAK USA®

    Made in Türkiye

    Single Cylinder Compressor

    YUMAK USA® No 178 100 1001
    GTIN: 8680437282792
    Brand New — No Core Charge — This is a brand-new part. No core deposit is charged and no old (core) unit return is required.

    OEM Numbers

    Paccar
    2121411 2336600
    Mack
    6300-9122180027
    Wabco
    912 218 000 0 912 218 002 0 912 218 002 7
    Peterbilt
    2139800
    Volvo
    WAB9122180027

    Brand and Model

    Mack
    Paccar
    Peterbilt
    Volvo
    Technical Specifications

    Brand YUMAK Original

    Cylinder Diameter Ø3.94 in

    Volume 26.85 cu in

    Piston Operating Distance 2.2 in

    Port 0 Ø1.18 in

    Port 2 Ø0.79 in

    Port 4 M14X1,5

    Port 8.1 M22X1,5

    Port 9.1 M16X1,5

    Port 9.2 M16X1,5

    Number of Cylinders 1

    Cooling Water

    ESS Feature Yes

    Water Cooled Valve Plate Yes

    Direct Working Yes

    Maximum Operating Pressure 210 psi

    Weight 50.04 lb

    Used In Vehicles

    BrandModelEngine

    Mack

    Paccar

    Peterbilt

    Volvo

    Documents

    178 100 1001 request documents for Request
